Async Before at start event of a process did not read the setting of Retry Time Cycle

richard · May 9, 2016, 9:17am

Hello,

I have set the Async Before at a process’s start event, and set the retry cycle to “R15/PT1M”. However when the job is failed, it only retry for 3 times which is the default retry cycle instead of the one set in the Retry Time Cycle.

Anyone can explain what is wrong? Thanks a lot.

thorben · May 9, 2016, 9:25am

Hi Richard,

Which Camunda BPM version do you use? Which version of Camunda Modeler do you use?

Cheers,
Thorben

richard · May 9, 2016, 9:25am

Hi,

It is version 7.2.0.

thorben · May 9, 2016, 11:14am

Hi,

Do you use the old Eclipse-based modeler or the new bpmn-io-based standalone modeler?

Cheers,
Thorben

richard · May 10, 2016, 2:54am

Hi I am using the camunda modeler plugin available for eclipse, the version is 2.7.0.

Thanks.

thorben · May 10, 2016, 7:14am

Can you please post the process model? Then I can try to reproduce the problem.

Thanks,
Thorben

gdabski · August 24, 2016, 3:16pm

I’ve also stumbled across this. I’ve found that FoxFailedJobParseListener appears to only set the retry time cycle if the start event is a timer event.

if (type != null && type.equals(START_TIMER_EVENT)){ this.setFailedJobRetryTimeCycleValue(startEventElement, startEventActivity); }

Is this indeed the reason and then can we configure the retry strategy on regular start events?

Thanks,

praveen_buya · March 3, 2020, 11:57pm

Hi All,

i was just thinking if i can use retry time cycle configuration to get rid of this incident on start event as shown in image. But not sure if retry time cycle will cause any duplicates?

Will retry happens only if there is any incident happens on the start event step on camunda workflow as shown below?
