Camunda Deployment in Azure Kubernetes Service (AKS)

[1986sudipta]

I am new in Camunda 8 . For learning purpose , I have successfully installed Camunda8 in AKS cluster using following tutorial .

Camunda 8 Self Managed Installation to Microsoft AKS

But I am not able to connect Camunda 8 from Camunda desktop modeler . Attaching screenshot for Camunda desktop modeler log

Need help

.

[1986sudipta]

This is inform you that i am starting modeler through a batch file as per suggestion from this POST :

Getting error while deploying the model to Camunda hosted on PCF

Hello All - I am getting the below error while deploying the bpmn file to Camunda instance hosted on PCF(on-prem). It looks like a certificate issue and I will have to work on the certs related issue on my own, but, I am also looking to see if someone else got the same error too and if so how did you fix it. Deploy error: {“code”:“UNABLE_TO_VERIFY_LEAF_SIGNATURE”,“deploymentName”:“demo”,“errno”:“UNABLE_TO_VERIFY_LEAF_SIGNATURE”,“message”:“request to https://apps.system..*****.**********.int/en…

My first error is : RequestError: unable to verify the first certificate

When i set the above command (as per image attached )
I am getting following error :

Error: 13 INTERNAL: Received RST_STREAM with code 0

[cpbpm]

Go through the documentation and install the Cert on your system to make secure connection.

Troubleshooting | Camunda 8 Docs

[nathan.loding]

Hi @1986sudipta - the “RST_STREAM with code 0” message means that communication with the gRPC server was closed prematurely, which often indicates a network issue. gRPC requires HTTP/2 - the first thing I would check is to make sure that your AKS ingress is configured to accept HTTP/2 connections.

Another thing you can do to eliminate Modeler as being an issue is to use a different tool, such as zbctl. If zbctl connects but Modeler doesn’t, then the issue with Modeler (or the configuration inside Modeler); if neither connect, the issue is likely with the deployment.
